Echelon Diamond E1060i* Features
Model
Echelon Diamond E1060i*
Cooking Surface
1056 square inches (48″ x 22″)
BTUs primary
115,000
BTUs backburner
11,000 (x2)
Cut out
50” w 23 ½” d x 12” h
Material
All 300 Series stainless steel
Wood chip smoker with dedicated 3,000 BTU’s burner
Cast stainless steel burners (E-burners)
All stainless steel cooking grids
Contoured control panel
16 gauge stainless steel flavor grids
Back lit safety knobs
Optional magic view window
Heat zone separators
Electronic digital thermometer or analog thermometer
Halogen lamps for evening grilling
15 YEAR WARRANTY ON BACKBURNERS
Cast stainless steel burners, stainless steel housing and stainless steel cooking grids are warranted for as long as you own your grill
Be sure to view our built-in accessories.
Echelon Diamond E7901i* Features
Model
Echelon Diamond E7901i*
Cooking Surface
792 sq. inches (36” x 22”)
BTUs primary
99,000
BTUs backburner
13,000
Cut out
37”w x 23 ½”d x 12” h
Material
All 300 Series stainless steel
Wood chip smoker with dedicated 3,000 BTU’s burner
Cast stainless steel burners (E-burners)
All stainless steel cooking grids
Contoured control panel
16 gauge stainless steel flavor grids
Back lit safety knobs
Optional magic view window
Heat zone separators
Electronic digital thermometer or analog thermometer
Halogen lamps for evening grilling
15 YEAR WARRANTY ON BACKBURNERS
Cast stainless steel burners, stainless steel housing and stainless steel cooking grids are warranted for as long as you own your grill.
Be sure to view our built-in accessories.
Echelon Diamond E660i Features
Model
Diamond Echelon E660i
Cooking Surface
660 sq. inches (30” x 22”)
BTUs primary
78,000
BTUs backburner
11,000
Cut out
31 ¼”w x 23 ½” d x 12” h
Material
All 300 Series stainless steel
Wood Chip smoker with dedicated 3,000 BTU burner
Cast stainless steel burners (E-burners)
Contoured control panel
16 gauge stainless steel flavor grids
Back lit safety knobs
Optional Magic View Window
Heat zone separators
Electronic digital thermometer or analog thermometer
Halogen lamps for evening grilling
Available with Double Side Burner or Single Side Burner
15 YEAR WARRANTY ON BACKBURNERS
Cast stainless steel burners, stainless steel housing and stainless steel cooking grids are warranted for as long as you own your grill
Be sure to view our built-in accessories.
